Overview
The USB C8051F Debugger provides the interface between the PC's USB port and the target device's in-system debug/programming circuitry. The attached 10-pin
DEBUG ribbon cable connects the adapter to the target board and the target device's debug interface. The USB C8051F Debugger supports both Silicon Laboratories
JTAG and C2 debug interfaces. Power is provided to the adapter from the USB connection to the PC. The USB C8051F Debugger is capable of providing power to a
circuit board via pin 10 of the DEBUG connector.
Key features
Jtag and C2 Debug Interface
10-pin ribbon cable provided for connection to a target board with the appropriate connector, the figure below shows the pin definitions:
Related Software
All the devices from C8051Fxxx MCUs are supported.
Refer to Silicon Laboratories IDE 3.42.00 or Keil V3.80, the following devices are supported:
|
JTAG |
C8051F00x C8051F01x C8051F02x C8051F04x C8051F06x C8051F12x C8051F2xx |
|
C2 |
C8051F3xx C8051F41x C8051F5xx C8051F7xx C8051F8xx C8051F9xx |
This product should include the following components:
C8051 Debug Adapter , 1 pcs;
USB2.0 Cable,1pcs
10-pin ribbon cable,1pcs
